202
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
Part Number Description Location
288100112003 DIODE;EC11FS2-TE12L,SCHOTTKY,200 PD1,PD2
288103104001 DIODE;EC31QS04-TE12L,40V,3A,SMT PD501,PD505,PD7
288103104001 DIODE;EC31QS04-TE12L,40V,3A,SMT PD5,PD502,PD6,PD7,PD9
288100805001 DIODE;ESD0805A,1CH,15KV,0805,2P D30,D31,D32,D33,D513,D5
1
288100805001 DIODE;ESD0805A,1CH,15KV,0805,2P D1,D2
288105232001 DIODE;MMBZ5232BL,5.6V,ZENER,SOT-
288104148001 DIODE;RLS4148,200MA,500MW,MELF,S D2,D21
288100020001 DIODE;RLZ20C,ZENER,19.23V,5%,SMT PD501
288100024002 DIODE;RLZ24D,ZENER,23.63V,5%,SMT PD1
288100056001 DIODE;RLZ5.6B,ZENER,5.6V,5%,LL34 D1,D19
288100056005 DIODE;UDZ5.6B,ZENER,5.6V,UMD2,SM D17
288100018003 DIODE;UDZS18B,ZENER,18V,SOD-323,
323760000023 DRAM MODULE;128M,SDRAM,PC133,SO-
344672300025 DUMMY CARD;PCMCIA,MANGUSTA
523430075004 DVD DRIVE;8X,DV-28E-B93,H=12.7
451673500003 DVD ME KIT;8X,TEAC,DV-28E-B93,WE
523467350002 DVD ROM ASSY;8X,TEAC,DV-28E-B93,
312271006152 EC;100U ,10V,M,RA,D6.3*9.8,OS-CO PC518
272602107501 EC;100U,16V,M,6.3*5.5,-55+85'C,S C626,C630,C631
312271006358 EC;100U,25V,RA,M,D6.3*7,SGX,SANY PC517
312271005357 EC;10U,25V,20%,RA,6.3*6.8,+105

PC512,PC515
312272205051 EC;22U,20V,M,RA,D6.3,-55+105,OS- PC502
312272263511 EC;22U,25V,20%,RA,8*10.5,105

,O P C501,PC504,PC506
312276806156 EC;680U,6.3V,+-20%,D10X12.5,6PS6 PC521
312278206155 EC;820U,4V,+-20%,D10X12.5,4PS820 PC502,PC505,PC508,PC510
,
Part Number Description Location
227673500004 END CAP;L,WEASEL
227673500003 END CAP;R,WEASEL
481673510002 F/W ASSY;KBD CTRL,WEASEL-AMD U6
481673510001 F/W ASSY;SYS/VGA BIOS,EOS,WEASEL U513
273000610008 FERRITE ARRAY;120OHM/100MHZ,TKIN FA1,FA501
273000130001 FERRITE CHIP;120OHM/100MHZ,1608, L12,L21,L27,L33,L508,L509
,
273000130019 FERRITE CHIP;120OHM/100MHZ,1608, L3,L4
273000150013 FERRITE CHIP;120OHM/100MHZ,2012, L22,L23,L24,L26,L28,L5,L5
1
273000150013 FERRITE CHIP;120OHM/100MHZ,2012, L504,L505,L509,L510,PL1,P
273000130010 FERRITE CHIP;130OHM/100MHZ,1608, L506,L507
273000150001 FERRITE CHIP;220OHM/100MHZ,2012,
273000130006 FERRITE CHIP;600OHM/100MHZ,.2A,1 L1,L10,L14,L17,L19,L20,L2
9
273000130006 FERRITE CHIP;600OHM/100MHZ,.2A,1 L501,L502,L503
422673500001 FFC;TOUCH PAD,WEASEL
346664900010 FILM;LCD PROTEC,.14.2",235*300,5
341672200001 FLAT SPRING;EMI,HDD,8500
245600010016 FLOW CARD;SPS,GRAY
245600010030 FLOW CARD;SPS,PINK,100MM*30MM,PR
245600010030 FLOW CARD;SPS,PINK,100MM*30MM,PR
344673500027 FRAME;SCROLL BUTTON,WEASEL
295000010028 FUSE;0.14A/60V,POLY SWITCH,PTC,S F3
295000010048 FUSE;0.5A/15V,POLY SWITCH,SMD F2
295000010105 FUSE;1A,NORMAL,1206,SMT F4
295000010057 FUSE;228R,139C',5A/250V,SMT,PRC
295000010116 FUSE;FAST, 10A, 86VDC, 6125,SMT PF1,PF2
9. Spare Parts List -4
