MiTAC E-8590 - Page 207

206
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
Part Number Description Location
222600020510 PE BAG;0.05*200*150mm,NBB METAL,
222670820003 PE BAG;L560*W345,7521N
222671330003 PE BAG;LCD BRACKET,STINGRAY
222503220001 P E BUBBLE BAG;BAT T ERY,GRAMP US
411503200201 PWA;PWA-WEASEL/BATT GAUGE BD,LI,
411503200202 PWA;PWA-WEASEL/BATT GAUGE BD,PAN
411673510005 PWA;PWA-WEASEL-AMD,CHARGER BD,SM
411673510004 PWA;PWA-WEASEL-AMD,CHARGER BD,T/
411673510001 PWA;PWA-WEASEL-AMD,EOS,128M,MOTH
411673510002 PWA;PWA-WEASEL-AMD,EOS,128M,MOTH
411673510003 PWA;PWA-WEASEL-AMD,EOS,128M,MOTH
411673510006 PWA;PWA-WEASEL-AMD,LED BD
332810000034 PWR CORD;250V/2.5A,2P,BLK,EU,175
271045037101 RES;.003 ,1W ,1% ,2512,SMT PR1,PR2
271045087101 RES;.008 ,1W ,1% ,2512,SMT PR501,PR503
271045107101 RES;.01 ,1W ,1% ,2512,SMT PR30
271045207101 RES;.02 ,1W ,1% ,2512,SMT PR6
271046507101 RES;.05 ,2W ,1% ,2512,SMT,PRC
271002000301 RES;0 ,1/10W,5% ,0805,SMT
J
S12,JS13,JS501,JS502,L5
1
271002000301 RES;0 ,1/10W,5% ,0805,SMT
271071000002 RES;0 ,1/16W,5% ,0603,SMT D14,D15,L526,PR16,PR21,P
271071000002 RES;0 ,1/16W,5% ,0603,SMT PR4,PR5
271071000002 RES;0 ,1/16W,5% ,0603,SMT R2
271071152101 RES;1.5K ,1/16W,1% ,0603,SMT R25,R26
271071152302 RES;1.5K ,1/16W,5% ,0603,SMT R152,R60,R669,R80
Part Number Description Location
271071100302 RES;10 ,1/16W,5% ,0603,SMT PR3,PR4,PR8,R533,R559,R
5
271071102211 RES;10.2K,1/16W,1% ,0603,SMT PR20
271071101101 RES;100 ,1/16W,1% ,0603,SMT R33,R36,R37,R38,R39,R43,
R
271071101301 RES;100 ,1/16W,5% ,0603,SMT R636
271071101301 RES;100 ,1/16W,5% ,0603,SMT
271071104101 RES;100K ,1/16W,1% ,0603,SMT PR501
271071104101 RES;100K ,1/16W,1% ,0603,SMT R16,R13
271071104101 RES;100K ,1/16W,1% ,0603,SMT
271071104302 RES;100K ,1/16W,5% ,0603,SMT PR18,PR33,R117,R155,R15
8
271071104302 RES;100K ,1/16W,5% ,0603,SMT PR21,PR26,PR28,PR31,PR3
3
271071104302 RES;100K ,1/16W,5% ,0603,SMT
271071103101 RES;10K ,1/16W,1% ,0603,SMT PR19,PR23,PR27,PR9,R619,
271071103101 RES;10K ,1/16W,1% ,0603,SMT PR32,PR35,PR40
271071103101 RES;10K ,1/16W,1% ,0603,SMT R8,R18,R19
271071103302 RES;10K ,1/16W,5% ,0603,SMT R110,R116,R125,R126,R127
271071103302 RES;10K ,1/16W,5% ,0603,SMT
271071106301 RES;10M ,1/16W,5% ,0603,SMT R623
271071118271 RES;11.8K,1/16W,0.1%,0603,SMT PR2
271071111301 RES;110 ,1/16W,5% ,0603,SMT PR5
271071113001 RES;113 ,1/16W,1% ,0603,SMT R53
271071121301 RES;120 ,1/16W,5% ,0603,SMT R96,R97,R98,R99
271071133311 RES;133K ,1/16W,1% ,0603,SMT R517
271071141102 RES;140 ,1/16W,1% ,0603,SMT R516
271071143701 RES;14K ,1/16W,0.1% ,0603,SMT P R13
271071150301 RES;15 ,1/16W,5% ,0603,SMT R9
9. Spare Parts List -8
