207
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
Part Number Description Location
271071151302 RES;150 ,1/16W,5% ,0603,SMT R1,R2,R3
271071154101 RES;150K ,1/16W,1% ,0603,SMT R1,R6
271071154301 RES;150K ,1/16W,5% ,0603,SMT R553
271071153301 RES;15K ,1/16W,5% ,0603,SMT R195,R196,R198,R199
271071163101 RES;16K ,1/16W,1% ,0603,SMT PR29,PR30,R606
271071178311 RES;178K ,1/16W,1% ,0603,SMT PR15
271071183101 RES;18K ,1/16W,1% ,0603,SMT R5
271071102102 RES;1K ,1/16W,1% ,0603,SMT R14
271071102302 RES;1K ,1/16W,5% ,0603,SMT R100,R160,R512,R544,R549
271071102302 RES;1K ,1/16W,5% ,0603,SMT
271071105101 RES;1M ,1/16W,1% ,0603,SMT P R1,PR34
271071105301 RES;1M ,1/16W,5% ,0603,SMT P R14,R153,R180,R206,R57
7
271071105301 RES;1M ,1/16W,5% ,0603,SMT P R14,PR16,PR17
271071105301 RES;1M ,1/16W,5% ,0603,SMT
271071222302 RES;2.2K ,1/16W,5% ,0603,SMT R123,R124,R29,R520,R571,
R
271071225301 RES;2.2M,1/16W,5% ,0603,SMT
271071249111 RES;2.49K,1/16W,1% ,0603,SMT PR41
271071272301 RES;2.7K ,1/16W,5% ,0603,SMT PR10
271071203101 RES;20K ,1/16W,1% ,0603,SMT PR3
271071203101 RES;20K ,1/16W,1% ,0603,SMT R30,R17
271071203302 RES;20K ,1/16W,5% ,0603,SMT PR11,R596
271071221302 RES;22 ,1/16W,5% ,0603,SMT R136,R142,R143,R166,R169
271002220303 RES;22 ,1/8W,5% ,0805,SMT R119,R81
271071224301 RES;220K ,1/16W,5% ,0603,SMT R185
271071223302 RES;22K ,1/16W,5% ,0603,SMT PR13,R165,R168
Part Number Description Location
271071249311 RES;249K ,1/16W,1% ,0603,SMT PR37
271071261311 RES;261K ,1/16W,1% ,0603,SMT
271071270301 RES;27 ,1/16W,5% ,0603,SMT R648,R650,R657,R659,R660
271071271301 RES;270 ,1/16W,5% ,0603,SMT PR25,R90
271071202102 RES;2K ,1/16W,1% ,0603,SMT R204,R212,R605,R618
271071205101 RES;2M ,1/16W,1% ,0603,SMT R11
271071332302 RES;3.3K ,1/16W,5% ,0603,SMT R202
271071301101 RES;300 ,1/16W,1% ,0603,SMT R14
271071301011 RES;301 ,1/16W,1% ,0603,SMT R521
271071301311 RES;301K ,1/16W,1% ,0603,SMT PR502
271071303101 RES;30K ,1/16W,1% ,0603,SMT R3
271071324211 RES;32.4K,1/16W,1% ,0603,SMT PR26
271071324012 RES;324K ,1/16W,1% ,0603,SMT PR42
271071330302 RES;33 ,1/16W,5% ,0603,SMT R120,R6
271071331301 RES;330 ,1/16W,5% ,0603,SMT R5,R6
271071333301 RES;33K ,1/16W,5% ,0603,SMT PR22,PR7,R2,R503
271071302101 RES;3K ,1/16W,1% ,0603,SMT R604
271001435301 RES;4.3M,1/10W,5%,0805,SMT R10
271002472301 RES;4.7K ,1/10W,5% ,0805,SMT PR43,PR44
271071472302 RES;4.7K ,1/16W,5% ,0603,SMT R13,R131,R132,R133,R137,
R
271071472302 RES;4.7K ,1/16W,5% ,0603,SMT PR11,PR24,PR25
271071499111 RES;4.99K,1/16W,1% ,0603,SMT PR20,PR23
271071402811 RES;40.2 ,1/16W,1% ,0603,SMT R52,R58
271071471101 RES;470 ,1/16W,1% ,0603,SMT R21,R23,R27
271071471302 RES;470 ,1/16W,5% ,0603,SMT R35
9. Spare Parts List -9
