208
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
Part Number Description Location
271071471302 RES;470 ,1/16W,5% ,0603,SMT
271071474301 RES;470K ,1/16W,5% ,0603,SMT R1,R159,R548,R7
271071474301 RES;470K ,1/16W,5% ,0603,SMT PR27
271071473301 RES;47K ,1/16W,5% ,0603,SMT R205
271071473301 RES;47K ,1/16W,5% ,0603,SMT PR12,R1,R504
271071499811 RES;49.9 ,1/16W,1% ,0603,SMT R107,R111,R122,R129
271071562111 RES;5.62K,1/16W,1% ,0603,SMT R68
271071562301 RES;5.6K ,1/16W,5% ,0603,SMT R193,R23,R581,R671
271071513701 RES;51K,1/16W,.1%,0603,SMT R4
271071536211 RES;53.6K,1/16W,1% ,0603,SMT PR24
271071560301 RES;56 ,1/16W,5% ,0603,SMT R50,R51
271071561101 RES;560 ,1/16W,1% ,0603,SMT R22,R24,R28
271071576311 RES;576K ,1/16W,1% ,0603,SMT PR19
271071619111 RES;6.19K,1/16W,1% ,0603,SMT PR39
271071649111 RES;6.49K,1/16W,1% ,0603,SMT R147
271071682301 RES;6.8K ,1/16W,5% ,0603,SMT R213,R214,R215,R216,R675
271071604811 RES;60.4 ,1/16W,1% ,0603,SMT R522,R523,R62,R63
271071684101 RES;680K ,1/16W,1% ,0603,SMT PR38
271071698311 RES;698K ,1/16W,1% ,0603,SMT
271071750101 RES;75 ,1/16W,1% ,0603,SMT R105,R108,R113,R115,R16,
271071751101 RES;750 ,1/16W,1% ,0603,SMT R15
271071806211 RES;80.6K,1/16W,1% ,0603,SMT PR12
271071825211 RES;82.5K,1/16W,1% ,0603,SMT R12,R7
271071931211 RES;93.1K,1/16W,1% ,0603,SMT PR10
271071976311 RES;976K ,1/16W,1% ,0603,SMT PR18,PR8
Part Number Description Location
271611000301 RP;0*4 ,8P ,1/16W,5% ,0612,SMT RP15,RP16,RP5,RP515
271611152301 RP;1.5K*4,8P ,1/16W,5% ,0612,SMT RP8
271571100301 RP;10*8 ,16P ,1/16W,5% ,1606,SM RP503,RP504,RP505,RP506
271611103301 RP;10K*4 ,8P ,1/16W,5% ,0612,SMT RP11,RP12,RP20
271621103303 RP;10K*8 ,10P,1/16W,5% ,1206,SMT RP502,RP512,RP523,RP536
271611153301 RP;15K*4 ,8P ,1/16W,5% ,0612,SMT RP31
271611102301 RP;1K*4 ,8P ,1/16W,5% ,0612,SMT RP6,RP7
271621102303 RP;1K*8 ,10P,1/16W,5% ,1206,SMT RP1,RP10,RP9
271611220301 RP;22*4 ,8P ,1/16W,5% ,0612,SMT RP18,RP19,RP531
271611330301 RP;33*4 ,8P ,1/16W,5% ,0612,SMT RP24,RP26,RP27,RP28,RP2
271611472301 RP;4.7K*4,8P ,1/16W,5% ,0612,SMT RP13,RP14,RP511,RP514
271621472303 RP;4.7K*8,10P,1/16W,5% ,1206,SMT RP2,RP21,RP22,RP23,RP25
271621473301 RP;47K*8 ,10P,1/16W,5% ,1206,SMT RP17,RP513
271611750301 RP;75*4 ,8P ,1/16W,5% ,0612,SMT RP3
345503200203 RUBBER FOOT;29*7.5*1.5MM,WEASEL
345503200202 RUBBER;10*10*1.8MM,WEASEL
345672300002 RUBBER;LCD,DOWN,MANGUSTA
345503200201 RUBBER;SEMICIRCLE,2MM,WEASEL
371102010252 SCREW;M2L2.5,K-HEAD(+),NIB/NLK
371102010252 SCREW;M2L2.5,K-HEAD(+),NIB/NLK
371102030801 SCREW;M2L8,FLT(+),NIB/NLK
371103030602 SCREW;M3L6,K-HEAD(+),NIB/NLK
340673500009 SHIELD ASSY;TOP,WEASEL
342673500002 SHIELD;TOP,WEASEL
340670500011 SHIELDING ASSY;HDD,TETRA
9. Spare Parts List -10
