MiTAC E-8590 - Page 210

209
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
Part Number Description Location
342670500003 SHIELDING;HDD,T ETRA
333050000107 SHRINK TUBE;UL,600V,105'C,ID2.5*
333050000117 SHRINK TUBE;UL,600V,105'C,ID2.5*
361400003021 SOLDER CREAM;NOCLEAN,P4020870980
361400003021 SOLDER CREAM;NOCLEAN,P4020870980
361400003021 SOLDER CREAM;NOCLEAN,P4020870980
600100010009 SOLDER WIRE;63/37,0.8,CM,N/C,PRC
600100010005 SOLDER WIRE;63/37,0.8,NA,N/C,PRC
346670500008 SPACER;SOCKET 462,TETRA
370102610401 SPC-SCREW;M2.6L4,K-HD,t0.8,NIB/N
370102610401 SPC-SCREW;M2.6L4,K-HD,t0.8,NIB/N
370102610405 SPC-SCREW;M2.6L4,NIW,K-HD,t=0.8,
370102610603 SPC-SCREW;M2.6L6,K-HD,NIB/NLK
370102610603 SPC-SCREW;M2.6L6,K-HD,NIB/NLK
370102010204 SPC-SCREW;M2L2,NIW/NLK,K-HD
370102010407 SPC-SCREW;M2L4,K-HD,NIB/NLK
370102010407 SPC-SCREW;M2L4,K-HD,NIB/NLK
370102010407 SPC-SCREW;M2L4,K-HD,NIB/NLK
370103010405 SPC-SCREW;M3L4,NIW,K-HD,T0.3
421673500004 SPEAKER ASSY;L,WEASEL
421673500003 SPEAKER ASSY;R,WEASEL
345673500003 SPONGE;RTC BATTERY,WEASEL
342670500005 STAND OFF;MDC,TETRA
341670400006 STANDOFF;HEATSINK,GRAMPUS
341600000262 STEELPLATE;0.3*140*CMM,SUS301,PR
Part Number Description Location
344669600037 STOPPER;CUP SOCKET,RACE
295000020002 SURGE PROTECTOR;P2600SB,2P,DO-21 R148
297040101003 SW;PUSH BUTTON,SPST,.1A,30V,2P,S SW2,SW4
297040102002 SW;PUSH BUTTON,SPST,15V/20MA,H3. SW3,SW5,SW6,SW7
297040102002 SW;PUSH BUTTON,SPST,15V/20MA,H3. SW1
297030105003 SW;TOGGLE,SPST,5V/1mA,MPU-101-80 SW2
225600000309 TAPE;3M-467/DOUBLE RELEASE PAPER
225600000310 TAPE;ADHENSIVE,DOUBLE-FACE,W8,UL
225600000152 TAPE;G9000,W=10,PRC
225600000054 TAPE;INSULATING,POLYESTER FILM,1
225600000051 TAPE;MARGIN,COMPOSITE FILM,4.0MM
346673500009 THERMALP AD;55x20x1.2,WEASEL
310111103011 THERMISTOR;10K,1%,RA,DISK,103AT-
340666600018 TILT UNIT;L,TITAN
340666600017 TILT UNIT;R,TITAN
442600000071 TOUCH PAD MODULE;TM141PUM311-12
288227002006 TRANS;2N7002LT1,N-CHANNEL FET,ES P Q1,PQ2,PQ4,PQ5
288227002006 TRANS;2N7002LT1,N-CHANNEL FET,ES PQ12,PQ3,PQ5,PQ9
288227002001 TRANS;2N7002LT1,N-CHANNEL FET,SO Q12,Q13,Q15,Q16,Q17,Q19,
288200301004 TRANS;3LN01S,N-MOSFET,SMCP Q2
628820014401 TRANS;DTA144EKA,PNP,100MA,50V,SO
288200144002 TRANS;DTA144WK,PNP,SMT PQ10
288200114001 TRANS;DTC114TKA,10K,N-MOSFET,SOT Q34,Q35
288200144003 TRANS;DTC144TKA,N-MOSFET,SOT-23 Q11,Q26,Q30,Q5,Q504
288200144001 TRANS;DTC144WK,NPN,SOT-23,SMT Q2,Q24,Q27,Q29,Q33,Q505,
9. Spare Parts List -11
