Output Features:
1 - Pair of differential CPU clocks @ 3.3V (CK408)
1 - Pair of differential open drain CPU clocks (K7)
1 - Pair of differential push pull CPU_PP clocks @ 2.5V
3 - AGP @ 3.3V
7 - PCI @ 3.3V
1 - 48MHz @ 3.3V fixed
1 - 24_48MHz @ 3.3V
2 - REF @ 3.3V, 14.318MHz
Key Specifications:
CPU_CS - CPUT/C: <±250ps
CPU_CS - AGP: <±250ps
CPU - DDR/SD: <±250ps
PCI - PCI: <500ps
CPU - PCI: Min = 1.0ns, Typ = 2.0ns, Max = 4.0ns
