21/1531-ASP11301 Uen B3 2016-02-17 12
I
NSTALLING BOARDS
Figure 7: MGU Front Connectors with 40mm front
Figure 8: MGU2 with 20mm front
Status LED:
Green
Red
Green flashing
Red flashing
See the MGU
description for
details.
E1/T1
USB
MGU
RESET button Status LED (Green, Red, Green flashing, Red flashing)
LAN connections
USB connection
E1/T1 connections
Reset
LAN1
LAN0
1
2 3 4
(behind front)
Key hole
See the MGU2 description for details.
