5-500 High-speed RAM operation function
5Functions set with parameters
Fig.5-4:High-speed RAM operation image
The DRAM memory is used when executing high-speed RAM operation. The DRAM memory can perform
high-speed processing, which is about 1.2 times faster than the SRAM memory at maximum. (The speed
varies depending on the program contents.)
Note that robot operations, such as program execution and step operation, can be performed in the same
manner as the SRAM, but some restrictions apply. Refer to the following precautions.
Power ON
Parameter
RAM
mode (0)
High-speed
RAM mode
(2)
* Default setting
File System
SRAM
Area
Execution Area
DRAM Area
(high-speed
execution)
SRAM Area
(save enabled)
・ Target of executable programs
・ Programs to be backed up
・ Changing parameters
・ Saving error logs
・ Reading programs
・ Editing (writing) programs
・ Copying, moving and renaming
programs, etc.
・ Files accessed with OPEN
instruction
・ Program execution area
・ Save execution results
・ Execution results can be saved
with conditions
File System
SRAM
Area
Execution Area
DRAM Area
(high-speed
execution)
SRAM Area
(save enabled)
・ Execution results can be saved
To Next Page
