6-558 Sequencer link I/O function
6External input/output functions
IODATA
Numeric value input 4 Numeric value output 4 10036 10036
G10002
Numeric value input 5 Numeric value output 5 10037 10037
Numeric value input 6 Numeric value output 6 10038 10038
Numeric value input 7 Numeric value output 7 10039 10039
Numeric value input 8 Numeric value output 8 10040 10040
Numeric value input 9 Numeric value output 9 10041 10041
Numeric value input 10 Numeric value output 10 10042 10042
Numeric value input 11 Numeric value output 11 10043 10043
Numeric value input 12 Numeric value output 12 10044 10044
Numeric value input 13 Numeric value output 13 10045 10045
Numeric value input 14 Numeric value output 14 10046 10046
Numeric value input 15 Numeric value output 15 10047 10047
HNDCNTL1
- Hand output signal state 900 - 10048
G10003
- Hand output signal state 901 - 10049
- Hand output signal state 902 - 10050
- Hand output signal state 903 - 10051
- Hand output signal state 904 - 10052
- Hand output signal state 905 - 10053
- Hand output signal state 906 - 10054
- Hand output signal state 907 - 10055
HNDSTS1
- Hand input signal state 900 - 10056
- Hand input signal state 901 - 10057
- Hand input signal state 902 - 10058
- Hand input signal state 903 - 10059
- Hand input signal state 904 - 10060
- Hand input signal state 905 - 10061
- Hand input signal state 906 - 10062
- Hand input signal state 907 - 10063
USRAREA
- User-designated area 8-points 1 - 10064
G10004
- User-designated area 8-points 2 - 10065
- User-designated area 8-points 3 - 10066
- User-designated area 8-points 4 - 10067
- User-designated area 8-points 5 - 10068
- User-designated area 8-points 6 - 10069
- User-designated area 8-points 7 - 10070
- User-designated area 8-points 8 - 10071
Note1) The address of the multi-CPU share device. (Address seen from the sequencer CPU side)
Parameter
name
Input signal name
(*: Operation rights is necessity)
Output signal name Input Output
G device
Note1)
