3-74 Operating the monitor screen
3Explanation of operation methods
3) Display the ON/OFF state of the 32 points at the head for the input signal No. 8. Black painting indi-
cates ON and white indicates OFF.
Press the function key corresponding to "Next", then display the next input signal screen. Press the function
key corresponding to "Prev", then display the previous input screen.
4) Press the function key corresponding to "CLOSE", and return to the monitor menu screen.
5) Press the function key corresponding to "CLOSE" in monitor menu screen is pressed, finish the moni-
tor, and return to the original screen.
Next [F3]
Previous [F2]
<INPUT>
5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0
55 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 40
71 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 56
1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6
NUMBER
CLOSE
123
Next Prev
<INPUT>
3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8
23 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 8
39 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 24
9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4
NUMBER
CLOSE
123
Next Prev
<INPUT>
3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8
23 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 8
39 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 24
9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4
NUMBER
CLOSE
123
Next Prev
<MONITOR>
1.INPUT 2.OUTPUT
3.INPUT REG. 4.OUTPUT REG.
5.VARIABLE 6.ERROR LOG
CLOSE
123
<MONITOR>
1.INPUT 2.OUTPUT
3.INPUT REG. 4.OUTPUT REG.
5.VARIABLE 6.ERROR LOG
CLOSE
123
<FILE/EDIT> 1/20 Rem 136320
1 08-04-24 17:20:32 22490
2 08-04-24 14:56:08 694
A1 08-04-24 13:05:54 2208
B1 08-04-24 13:05:54 1851
COPY
123
POSI.
EDIT
NEW
⇒
Finish the monitor
If the [MONITOR] key is pressed, the monitor will be finished always and it will return to the original screen.
