3.9 H/W Error Time PLC Operation Mode Setting
This setting determines whether to stop or continue the CPU module operation when a hardware error (CPU module
detects SP.UNIT DOWN) occurs in the intelligent function module or the interrupt module.
(1) H/W error time PLC operation mode setting
Set the H/W error time PLC operation mode in the I/O Assignment tab of the PLC parameter dialog box.
(2) Precautions
The H/W error time PLC operation setting will be enabled when:
• the CPU module is powered off and then on, or
• the CPU module is reset.
1. Set I/O assignment.
2. Click the button.
3. Select "Stop" or "Continue" for the slot where the
H/W error time PLC operation mode is set. (Default:
"Stop")
