Appendix 1 Parameters Appendix 1.3 Network Parameters
Appendix 1.3 Network Parameters
This section describes network parameter details with setting windows.
Symbols, M and N, used in the "Parameter No." column
M and N in "Parameter No." in this section denote the following:
• N: Indicates the module number.
• M: Indicates the network type.
(1) For CC-Link IE, MELSECNET/H
(2) For CC-Link
M Network type
1
H
CC IE Control (Control station), MELSECNET/H mode (Control station), MELSECNET/H Extended mode
(Control station), MELSECNET/10 mode (Control station)
2
H
CC IE Control (Normal station), MELSECNET/H mode (Normal station), MELSECNET/H Extended mode
(Normal station), MELSECNET/10 mode (Normal station)
5
H
MELSECNET/H (Remote master station)
8
H
CC IE Field (Master station), CC IE Field (Submaster station) (when parameters are set)
9
H
CC IE Field (Local station), CC IE Field (Submaster station) (when no parameter is set)
A
H
MELSECNET/H (Standby station)
B
H
MELSECNET/H mode multiplexed remote I/O network master station
D
H
MELSECNET/H mode multiplexed remote I/O network sub-master station (when no parameter is set)
E
H
MELSECNET/H mode multiplexed remote I/O network sub-master station (when parameters are set)
M Network type
0
H
Master station
1
H
Local station
2
H
Standby master station
