CHAPTER 1 BASIC PROCEDURE FOR PROGRAMMING
1
1.5 Writing a Project to the CPU Module 1.5.2 Writing to the CPU module
1.5.2 Writing to the CPU module
Open the "Online Data Operation" dialog box. In this chapter, a project is written to the program memory.
[Online] [Write to PLC...]
The project has been written. In the next procedure, execute the program.
Note that parameter setting is required to operate CPU modules. In this chapter, the procedure for parameter setting is not
introduced since default values are used. ( Page 430, Appendix 1)
1) Select the program
memory.
2) Selecting this will
automatically select the
parameter and program
checkboxes.
