APPENDICES

Appendix 7 Precautions for Replacing QnPHCPU with QnUDPVCPU

Appendix 7 Precautions for Replacing QnPHCPU with

QnUDPVCPU

For the precautions for replacing the QnPHCPU with the QnUDPVCPU, refer to the following.

Technical bulletin: No. FA-A-0155 (Method of replacing Process CPU with Universal model Process CPU)

Appendix 8 Precautions for Using GX Works2 and

Differences with GX Developer

For the precautions for using GX Works2 and differences with GX Developer, refer to the following.

GX Works2 Version 1 Operating Manual (Common)
