(1) Setting method

To use the operation history function, select the "Save operation history of CPU module" checkbox in the PLC

RAS tab of the PLC parameter. ( Page 441, Appendix 1.2.4)

For a system where data is frequently written to devices and files, set a large capacity to save many histories. When setting

a large capacity, specifying the SD memory card is highly recommended as the save destination memory.
