CHAPTER 4 DEVICES

4.4 Link Direct Device

(b) Application example

For link register 10 (W10) of network number 2, "J2\W10" must be used.

For a bit device (X, Y, B, or SB), the digit must be specified.

Ex.

J1\K1X0, J10\K4B0

K100

J2\ W10

MOVP

LW 0

LW10

Network module of

network number 2
