392
(2) Storing data in an SRAM card
Up to 4086K points can be stored in one file.
Since one block consists of 32K words, up to 128 blocks can be stored.
Note that the number of points or blocks that can be added depends on the size of the programs and device
comments stored in the memory card.
(3) Storing data in a Flash card
Up to 2039K points can be stored in one file.
Since one block consists of 32K words, up to 64 blocks can be stored.
Note that the number of points or blocks that can be added depends on the memory card capacity and the size of
the programs and device comments stored in the memory card.
For the memory cards available for the CPU module, refer to Page 37, Section 2.1.1 (4).
Q06UDVCPU, Q06UDPVCPU 384K
With an extended SRAM cassette (1M) 896K
With an extended SRAM cassette (2M) 1408K
With an extended SRAM cassette (4M) 2432K
With an extended SRAM cassette (8M) 4480K
Q10UD(E)HCPU, Q13UD(E)HCPU 512K
Q13UDVCPU, Q13UDPVCPU 512K
With an extended SRAM cassette (1M) 1024K
With an extended SRAM cassette (2M) 1536K
With an extended SRAM cassette (4M) 2560K
With an extended SRAM cassette (8M) 4608K
Q20UD(E)HCPU, Q26UD(E)HCPU 640K
Q26UDVCPU, Q26UDPVCPU 640K
With an extended SRAM cassette (1M) 1152K
With an extended SRAM cassette (2M) 1664K
With an extended SRAM cassette (4M) 2688K
With an extended SRAM cassette (8M) 4736K
Q50UDEHCPU 768K
Q100UDEHCPU 896K
CPU module Point
