Mitsubishi Electric MELSEC-Q00U(J)CPU

439
APPENDICES
A
Appendix 1 Parameters Appendix 1.2 PLC parameters
Common Pointer No.
1005
H
Set the start number of common
pointers.
P0 to 4095 Blank
Page 409,
Section
4.10.2
Points Occupied by
Empty Slot
1007
H
Set the number of points for
empty slots on the
main/extension base units.
0, 16, 32, 64, 128, 256, 512, or 1024
Points
16 Points
Page 54,
Section 2.2.2
System
Interrupt
Settings
Fixed Scan
Interval (n:
28 to 31)
1008
H
Set each execution interval for
the interrupt pointers (I28 to I31).
0.5ms to 1000ms
(in increments of 0.5ms)
• I28: 100.0ms
• I29: 40.0ms
• I30: 20.0ms
• I31: 10.0ms
Page 410,
Section 4.11
High Speed
Interrupt
Setting
100F
H
to 1012
H
Set this parameter when a high-
speed interrupt pointer (I49) is
used.
--
Page 224,
Section 3.21
Interrupt Program/Fixed
Scan Program Setting
1008
H
Enable or disable high speed
execution of interrupt programs
or fixed scan programs.
Selected/deselected Deselected
Page 82,
Section 2.9,
Page 98,
Section
2.10.4
Service Processing
Setting
1013
H
Select any of the following
options.
• Execute the process as the
scan time proceeds.
• Specify service process time.
• Specify service process
execution counts.
• Execute it while waiting for
constant scan setting.
• 1 to 99% (in increments of 1%)
• 1 to 10 (in increments of 1 time)
• 0.2 to 1000ms (in increments of
0.1ms)
•Blank
Execute the
process as the
scan time
proceeds.: 10%
Page 240,
Section
3.24.1
PLC Module Change
Setting (PLC Module
Change Setting)
1017
H
Set items required when
performing the CPU module
change with memory card
function.
• Backup Start Setup Contact
• Backup Start Contact
• Backup Target Data
• Title Setting
Blank
Page 259,
Section 3.31
Item
Parameter
No.
Description Setting range Default Reference
