48
*1 The value will be adjusted by the system so that the total number of bytes of PLC parameters and network parameters
becomes multiple of four.
*2 The value will be adjusted by the system so that the total number of bytes becomes multiple of four.
*3 These are default values. (Values differ depending on the parameter setting).
*4 After the decimal point of a value obtained by a division part in the formula is rounded up.
*5 For the Q02UCPU, Q03UDCPU, Q04UDHCPU, or Q06UDHCPU whose serial number (first five digits) is "10011" or
earlier, apply the number of execution programs.
For a calculation example of memory capacity, refer to Page 51, Section 2.1.3 (4) (c).
System information file for CPU
module data backup/restoration
68 + (34 × (N + 1) + 34 × M) + L
• N: Number of target drives
• M: Number of target files
• L: Total size of file names of target files (including punctuation mark (.) and extension)
System data file for CPU module data
backup/restoration
64 + (6+ (a × 34)) + (6 + (a × (336 + (12 × b) + (12 × c))) + (6 + (d × 198)) + 22 + 5440 + (6 + e ×
6418))
• a: Sampling trace registration status
• b: Number of word device points of sampling trace information
• c: Number of bit device points of sampling trace information
• d: Data logging registration status
• e: Module error collection setting status
• For the status of a, d, and e, put “1” when they are registered/set and put “0” when they are not
registered/set to obtain the above calculation formula.
Device data file for CPU module data
backup/restoration
64 + 2 + 4 + 72 + (N × 8) + 11328 + ((a + (b 16) + (c × 2 16)) × 2)
• N: Number of target devices (for the timer, retentive timer, and counter, the contact and coil are
counted as one device.
• a: Number of word device points
• b: Number of bit device points (except for the timer, retentive timer, and counter)
• c: Number of bit device points (the timer, retentive timer, and counter)
Operation history file The file size depends on the parameter setting. (1K to 1024K bytes)
File type File size (unit: byte)
To Next Page
