Appendix 8 External Dimensions

Appendix 8 External Dimensions

Screw terminal block type

Spring clamp terminal block type

(Unit: mm)

(1) Center of DIN rail

(Unit: mm)

(1) Center of DIN rail

200

504.5

68

4

23

(1)

200

504.5

68

4

23

(1)
