1 PRODUCT LINEUP
1.1 Input Module
11
1
1 PRODUCT LINEUP
1.1 Input Module
1.2 Output Module
Module name Input specifications Module
power
supply
current
Weight Model Reference
AC input module Screw terminal block
100 to 120VAC, 16 points
64mA 0.31kg NZ2MFB2-16A Page 16 NZ2MFB2-
16A AC input module
Spring clamp terminal block
100 to 120VAC, 16 points
64mA 0.26kg NZ2MF2S2-16A Page 19
NZ2MF2S2-16A AC
input module
DC input module Positive common/
negative common
shared type
Screw terminal block
24VDC, 32 points
71mA 0.30kg NZ2MFB1-32D Page 22 NZ2MFB1-
32D DC input module
Spring clamp terminal block
24VDC, 32 points
71mA 0.25kg NZ2MF2S1-32D Page 25
NZ2MF2S1-32D DC
input module
Module name Output specifications Module
power
supply
current
Weight Model Reference
Contact output module Screw terminal block
240VAC/24VDC, 2A/point, 16
points
153mA 0.35kg NZ2MFB2-16R Page 28 NZ2MFB2-
16R contact output
module
Spring clamp terminal block
240VAC/24VDC, 2A/point, 16
points
153mA 0.30kg NZ2MF2S2-16R Page 31
NZ2MF2S2-16R contact
output module
Transistor output
module
Sink type Screw terminal block
12 to 24VDC, 0.5A/point, 32
points
85mA 0.30kg NZ2MFB1-32T Page 34 NZ2MFB1-
32T transistor output
module
Spring clamp terminal block
12 to 24VDC, 0.5A/point, 32
points
85mA 0.25kg NZ2MF2S1-32T Page 37
NZ2MF2S1-32T
transistor output module
Source type Screw terminal block
12 to 24VDC, 0.1A/point, 32
points
84mA 0.30kg NZ2MFB1-32TE1 Page 40 NZ2MFB1-
32TE1 transistor output
module
Spring clamp terminal block
12 to 24VDC, 0.1A/point, 32
points
84mA 0.25kg NZ2MF2S1-32TE1 Page 43
NZ2MF2S1-32TE1
transistor output module
