3 SPECIFICATIONS
3.2 Performance Specifications
3.2 Performance Specifications
Input module
NZ2MFB2-16A AC input module
*1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG. Multiple wires cannot be connected
to a terminal. Connecting two or more wires may cause a poor contact.
*2 It is recommended to use the bar solderless terminal for wiring.
Item NZ2MFB2-16A
Station type Slave station
Number of input points 16 points
Rated input voltage/rated frequency 100 to 120VAC (+10%/-15%), 50/60Hz (3Hz)
Rated input current 8.2mA (100VAC, 60Hz), 6.8mA (100VAC, 50Hz)
Inrush current 200mA maximum within 1ms
Input voltage distortion ratio Within 5%
Max. number of simultaneous input points 100%
ON voltage/ON current 80VAC or more/5mA or more (50Hz, 60Hz)
OFF voltage/OFF current 30VAC or less/1.7mA or less (50Hz, 60Hz)
Input impedance Approx. 15k (60Hz), approx. 18k (50Hz)
Input response time OFFON 20ms or less (100VAC 60Hz)
ONOFF
Withstand voltage 1400VACrms for 1 minute between all AC external terminals and the ground
510VACrms for 1 minute between all DC external terminals and the ground
Insulation resistance 10M or higher between all AC external terminals and the ground, all DC external terminals and the
ground (500VDC insulation resistance tester)
Noise immunity Noise voltage: 1500Vp-p (AC type), 500Vp-p (DC type), noise width 1s, noise frequency 25 to 60Hz
(noise simulator condition)
Protection degree IP1X
Wiring method for common 16 points/common (2-wire, screw terminal block type)
External interface Communication part RJ45 connector
Module power supply part Terminal block for module power supply and FG (Two-piece spring clamp terminal block)
I/O part 34-point one-piece terminal block
Tightening torque range for terminal screw (M3  5.2 screw): 0.59 to 0.88Nm
Applicable DIN rail TH35-7.5Fe, TH35-7.5Al (compliant with IEC 60715/JIS C 2812)
Applicable wire size For power supply Stranded wire: 0.3 to 1.5 (22 to 16 AWG), terminal slot size: 2.8mm  2.0mm
*2
For I/O Core: 0.3 to 2.0 (22 to 14 AWG)
Applicable solderless
terminal
Terminal block for module
power supply and FG
*1
Page 81 Applicable solderless terminal
Terminal block for input Page 84 Applicable solderless terminal
Number of occupied stations One station
Reference response time 1ms
Communication cable An Ethernet cable that meets the 100BASE-TX standard
For details, refer to the following.
 CC-Link IE Field Network Basic Reference Manual
Module power supply Voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC)
Current 64mA or less (24VDC, all points ON)
Weight 0.31kg
