3 SPECIFICATIONS
3.2 Performance Specifications
43
3
NZ2MF2S1-32TE1 transistor output module
*1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG or the terminal block for output.
Multiple wires cannot be connected to a terminal. Connecting two or more wires may cause a poor contact.
*2 It is recommended to use the bar solderless terminal for wiring.
Item NZ2MF2S1-32TE1
Station type Slave station
Number of output points 32 points
Rated load voltage 12/24VDC (ripple rate: 5% or less) (Allowable voltage range: 10.2 to 28.8VDC)
Max. load current 0.1A/point, 2A/common
Isolation method Photocoupler isolation
Max. inrush current Current is limited by the overload protection function.
Leakage current at OFF 0.1mA or less
Max. voltage drop at ON 0.1VDC(TYP.)0.1A, 0.2VDC(MAX.)0.1A
Output response time OFFON 0.5ms or less
ONOFF 1.5ms or less (resistance load)
Surge suppressor Zener diode
External power supply for
output part
Voltage 12/24VDC (ripple rate: 5% or less) (Allowable voltage range: 10.2 to 28.8VDC)
Current 25mA or less (TYP. 24VDC per common) External load current is not included.
Output type Source type
Withstand voltage 500VAC for 1 minute between all DC external terminals and the ground
Insulation resistance 10M or higher between all DC external terminals and ground (500VDC insulation resistance tester)
Noise immunity Noise voltage 500Vp-p, noise width 1s, noise frequency 25 to 60Hz (DC type noise simulator
condition)
Protection degree IP2X
Wiring method for common 32 points/common (two points) (1-wire, spring clamp terminal block type)
Protection function Overload protection
function
Limited current when detecting overcurrent: 1 to 3A/point
Activated to each point.
Overheat protection
function
Activated to two points.
External interface Communication part RJ45 connector
Module power supply part Terminal block for module power supply and FG (Two-piece spring clamp terminal block)
I/O part 34-point two-piece spring clamp terminal block
Applicable DIN rail TH35-7.5Fe, TH35-7.5Al (compliant with IEC 60715/JIS C 2812)
Applicable wire size For power supply Stranded wire: 0.3 to 1.5 (22 to 16 AWG), terminal slot size: 2.8mm  2.0mm
*2
For I/O Stranded wire: 0.3 to 1.5 (22 to 16 AWG), terminal slot size: 2.4mm  1.5mm
*2
Applicable solderless
terminal
Terminal block for module
power supply and FG
*1
Page 81 Applicable solderless terminal
Terminal block for
output
*1
Page 85 Applicable solderless terminal
Number of occupied stations One station
Reference response time 1ms
Communication cable An Ethernet cable that meets the 100BASE-TX standard
For details, refer to the following.
 CC-Link IE Field Network Basic Reference Manual
Module power supply Voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC)
Current 84mA or less (24VDC, all points ON)
Weight 0.25kg
