3 SPECIFICATIONS
3.2 Performance Specifications
29
3
■External connection
*1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG. Multiple wires cannot be connected
to a terminal. Connecting two or more wires may cause a poor contact.
FG
1
2
3
UNIT POWER
CABLE
1
2
3
Y01
COM B2
Y13
COM B4
Y25
COM B6
7
COM B8
Y49
COM B10
Y511
COM B12
Y613
COM B14
Y715
COM B16
Y817
COM B18
Y919
COM B20
YA21
COM B22
YB23
COM B24
YC25
COM B26
YD27
COM B28
YE29
COM B30
YF31
COM B32
COM A33
COM B34
+24V
24G
Y3
Signal name
Pin
No.
Non-insulated
Terminal block
for output
Terminal block for module
power supply and FG
*1
Module power
supply
Load
Load power
supply
Load
Internal circuit
100/200VAC
or 24VDC
