In multiple CPU systems, inputs and outputs of control modules can forcibly turned on/off.
Even when inputs and outputs of non-control modules are registered for forced on/off, the input/output devices in other CPU
modules and inputs and outputs of modules controlled by other CPU modules cannot be forcibly turned on/off. (The input/
output devices in the host CPU module can forcibly turned on/off.)
(d) Cancelling on/off registration data
The registered forced ON/OFF data can be canceled by GX Developer.
Once the registered data is canceled, the status of the forced on/off registered devices will be as follows.
Forced on/off setting can be cleared by:
• powering off and then on the CPU module,
• resetting the CPU module by the RUN/STOP/RESET switch, or
• resetting the CPU module by the remote RESET operation.
Table6.14 Status of devices after forced on/off registration data is canceled
Forced on/off registered device
Sequence program operations
(on/off) performed
Sequence program operations
(on/off) not performed
Input
Input from modules mounted on the base unit Uses the on/off status input from modules.
Input of the CPU module to be refreshed from LX
of a CC-Link IE Controller Network or
MELSECNET/H module
Used the on/off status refreshed via CC-Link IE Controller Network or
MELSECNET/H.
Input of the CPU module to be refreshed from
RX of a CC-Link module
Uses the on/off status refreshed via CC-Link.
Input other than above (outside of the refresh
range)
Uses the results of sequence
program operations.
Holds the forced on/off status.
Output
Output from modules mounted on the base unit
Outputs the results of sequence
program operations.
Holds the registered on/off status.
Output of the CPU module to be refreshed from
LY of a CC-Link IE Controller Network or
MELSECNET/H module
Output of the CPU module to be refreshed from
RY of a CC-Link module
Output other than above (outside of the refresh
range)
Outputs the results of sequence
program operations. (The results
are not output externally.)
Holds the forced on/off status.
