6 - 111
CHAPTER6 FUNCTIONS
1
2
3
4
5
6
7
8
6.19 System Protection
6.19.2 Remote password
(3) Flow from remote password setting to reflection of the password
Set a remote password ( (5) in this section) and then write it to the CPU module.
The remote password is transferred to the target module when the CPU module is powered off and then on or is
reset. ( (2) in this section)
Figure 6.74 Outline of a remote password
GX Developer
GX Developer
Transfers a remote
password to the
Ethernet module when
the CPU module is
powered off and then
on or is reset.
Checks the remote
password.
Sets,
changes, or
clears
the remote password and writes
the result to the CPU module.
Ethernet
Ethernet module
To Next Page
