CHAPTER8 PARAMETERS
1
2
3
4
5
6
7
8
8.1 PLC Parameters 8.1.1 Basic model QCPU
Table8.8 I/O assignment setting list (continued)
Item
Parameter
No.
Description Setting range Default Reference
Base
setting
Base model
name
0401
H
Set the model name of the main
base unit or extension base
unit. (Entered at user's
discretion. Do not use the one
for the CPU module.)
Up to 16 characters
Blank Section 4.1.2
Power model
name
Set the model name of the
power supply module on the
main base unit or extension
base unit. (Entered at user's
discretion. Do not use the one
for the CPU module.)
Up to 16 characters
Extension
cable
Set the extension cable name.
(Entered at user's discretion.
Do not use the one for the CPU
module.)
Up to 16 characters
Slots
Set the number of slots of the
main base unit or extension
base unit.
This setting must be done for all
base units.
2, 3, 5, 8, 10, or 12
Switch setting 0407
H
Set various switches of an
intelligent function module.
Refer to the manual for the
intelligent function module used.
Blank Section 6.10
Detailed
setting
Error time
output mode
0403
H
Set whether to clear or hold the
output in case of a stop error in
the control CPU.
Clear/Hold Clear Section 6.8
H/W error
time PLC
operation
mode
4004
H
Set whether to stop or continue
the operation of the control
CPU in case of a hardware
failure of the intelligent function
module.
Stop/Continue Stop Section 6.9
I/O response
time
0405
H
Set a response time for the
input module, high-speed input
module, I/O combined module,
or interrupt module.
• Input or I/O mix: 1ms, 5ms,
10ms, 20ms, or 70ms
• Hi input or Interrupt: 0.1ms,
0.2ms, 0.4ms, 0.6ms, or 1ms
• Input or I/O mix:
10ms
• Hi input or Interrupt:
0.2ms
Section 6.7
Control PLC 0406
H
Set the control CPU for the input/
output modules and intelligent
function module.
No.1, No.2, No.3, or No.4 No.1
QCPU User's
Manual (Multiple
CPU System)
