Mitsubishi 00JCPU User Manual

9 - 3
(2) High Performance model QCPU, Process CPU, and Redundant CPU
(To the next page)
Table9.2 Device list
Classification Type Device name
Default
Parameter-set
range
Reference
Points Range
Internal user device
Bit device
Input 8192 X0 to 1FFF Hexadecimal
Can be changed
within 29K words
*3
Section 9.2.1
Output 8192 Y0 to 1FFF Hexadecimal Section 9.2.2
Internal relay 8192 M0 to 8191 Decimal Section 9.2.3
Latch relay 8192 L0 to 8191 Decimal Section 9.2.4
Annunciator 2048 F0 to 2047 Decimal Section 9.2.5
Edge relay 2048 V0 to 2047 Decimal Section 9.2.6
Step relay 8192 S0 to 511/block Decimal Section 9.2.9
Link relay 8192 B0 to 1FFF Hexadecimal Section 9.2.7
Link special relay 2048 SB0 to 7FF Hexadecimal Section 9.2.8
Word device
Timer
*1
2048 T0 to 2047 Decimal
Section 9.2.10
Retentive timer
*1
0 (ST0 to 2047) Decimal
Counter
*1
1024 C0 to 1023 Decimal Section 9.2.11
Data register 12288 D0 to 12287 Decimal Section 9.2.12
Link register 8192 W0 to 1FFF Hexadecimal Section 9.2.13
Link special register 2048 SW0 to 7FF Hexadecimal Section 9.2.14
Internal system
device
Bit device
Function input 16 FX0 to F Hexadecimal
Cannot be
changed
Section 9.3.1
Function output 16 FY0 to F Hexadecimal Section 9.3.1
Special relay 2048 SM0 to 2047 Decimal Section 9.3.2
Word device
Function register 5 FD0 to 4 Decimal Section 9.3.1
Special register 2048 SD0 to 2047 Decimal Section 9.3.3
Link direct device
Bit device
Timer
*1
8192 Jn\X0 to 1FFF Hexadecimal
Cannot be
changed
Section 9.4
Retentive timer
*1
8192 Jn\Y0 to 1FFF Hexadecimal
Counter
*1
16384 Jn\B0 to 3FFF Hexadecimal
Data register 512 Jn\SB0 to 1FF Hexadecimal
Word device
Link register 16384 Jn\W0 to 3FFF Hexadecimal
Link special register 512 Jn\SW0 to 1FF Hexadecimal
Module access
device
Word device
Intelligent function
module device
65536
Un\G0 to 65535
*2
Decimal
Cannot be
changed
Section 9.5
Cyclic transmission area
device
*4
4096 U3En\G0 to 4095 Decimal Can be changed
Index register Word device Index register 16 Z0 to 15 Decimal
Cannot be
changed
Section 9.6
File register Word device File register 0 - - 0 to 1018k Section 9.7
Nesting - Nesting 15 N0 to 14 Decimal
Cannot be
changed
Section 9.8
Pointer -
Pointer 4096 P0 to 4095 Decimal
Cannot be
changed
Section 9.9
Interrupt pointer 256 I0 to 255 Decimal Section 9.10
