10 - 7
CHAPTER10 CPU MODULE PROCESSING TIME
1
10
3
4
5
6
7
8
10.1 Scan Time 10.1.2 Time required for each processing included in scan time
(2) Tracking time
This is the processing time required when the tracking function is used in a redundant system.
For tracking time, refer to the following.
QnPRHCPU User's Manual (Redundant System)
(3) Instruction execution time in END processing
This is the processing time of the DUTY instruction in END processing.
The user timing clock (SM420 to 424 and SM430 to SM434) specified with the DUTY instruction is turned on/off
during the END processing.
Note10.1Note1
(4) Instruction execution time
The instruction execution time is the time required for all instructions used in the program to be executed.
Remark
For the processing time required for each instruction, refer to the following.
MELSEC-Q/L Programming Manual (Common Instruction)
Table10.2 Instruction execution time in END processing
CPU module
Processing time in END processing
When set to 1 When set to 5
Q00JCPU 0.15ms 0.21ms
Q00CPU 0.14ms 0.19ms
Q01CPU 0.12ms 0.16ms
Q02CPU 0.02ms 0.02ms
Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU
0.01ms 0.01msQ02PHCPU, Q06PHCPU, Q12PHCPU, Q25PHCPU
Q12PRHCPU, Q25PRHCPU
Note1
Note10.1
The Basic model QCPU does not support the use of SM430 to SM434.
Basic
