2 - 7
● A pointer dedicated to the high-speed interrupt function (I49) Note2.1 is available as an interrupt pointer.Note1
When using I49, do not execute the following:
• Another interrupt pointer (interrupt pointer other than I49)
• Interrupt program
• Fixed scan execution type program
If any of the above pointer or program is executed, the interrupt program of I49 cannot be executed in the preset
interrupt cycles.
● Only one interrupt program can be created with one interrupt pointer number.
For details of the interrupt factors and interrupt pointers, refer to Section 9.10.
Note1
Note2.1
The Basic model QCPU, Q02CPU, Process CPU, and Redundant CPU do not support the use of the pointer dedicated
to the high-speed interrupt function (I49).
Basic
High
performance
Process
Redundant
FEND
EI
IRET
IRET
END
I0
I29
Interrupt
program (I29)
Interrupt
program (I0)
To Next Page
