Operation
mode
selection
lZID
The
inverter
operation
modes
include
operation
with
external
signals
and
operation
with
key
pad.
Operation
can
be
limited
to one
mode
or
can
be
carried
out
with
both
modes.
Setting value 1 Operation only
with
key pad
Setting value 2 Operation
only
with
external signals
Setting value 3
Operation trecuencv-: Set with key pad (direct setting or
~l!J
keys)
Start
signal",
External signal
input
(STF.
STR
terminals)
Setting value 4
Operation
frequency""
External
signal
input
(DCO
to
5V between
termtnalsz-s)
Start
signal'"
Input
with
key pad
(RUN
key)
(Note)
4.
[Factory
setting) 1
(Note)
1.
This
parameter
cannot
be
rewritten
during
operation. Er2
will
display if
writing
is
attempted.
2. Setting values 3 and 4 are set to use the external signals and key pad operation for the
operation frequency setting and
start
signals.
3. When set to 3, the operating frequency is set via key pad and analog signa! input is ignored.
4. When set to 4, the operating frequency is set via analog signal input.
-35-
