Common specifications
Control method Sinusoidal wave PWM control
*10
Output
frequency range
0.5 to 120Hz
(starting
frequency fixed
at
0.5Hz)
Frequency
Digital input
0.1Hz (less
than
100Hz).
1Hz (100Hz and more) with key
setting
pad operations
"
resolution
Analog input
1/500
of maximum setting frequency
0
Within
±0.5%
of set
output
frequency (
10 to +50OC)
0
Digital input
.~
Frequency
with key pad operations
~
stability
Analog input
Within
+1%
of maximum
output
frequency (25°C±10°C)
g
Voltage/frequency characteristics Base frequency between 50 and 120Hz selectable
~
e
Torque boost
Manual torque boost 0 to 15% selectable
"
Acceleration/deceleration 0.0.1 to 999sec. selectable (acceleration/deceleration set
0
characteristics separately)
u
0.1K.
O.2K
"'150% or more.
OAK,
0.75K···100% or more.
Braking
Regenerative
*8
1.5K
"'50%
or more
torque
IDC injection
3Hz or less Operation time, operation voltage adjustable
Stall prevention operation level
Operation current level(110 to 200%)selectable
"
Frequency setting signal
DC 0 to 5V
0
0
.~~
Input signat Starting signal
Forward/reverse
rotation commanded separately
i;:'u
Output
Alarm 1b contact
output
~.
signal
o~
>
Operation
status
Output frequency.
output
current *11 selectable
~
Key pad
i5
Alarm
Alarm code when protective function has been activated.
-50-
