Mitsubishi FREQROL-U100

-36-
• The following adjustment can be performed by selecting the calibration mode
(setting value 2),
(Refer to page 37 for details.)
• Parameter clear/cali'bration ICLrl
The parameter-all-clear or frequency setting signal calibration mode can be
selected. The
parameter-clear cannot be executed during operation. and Er2
will display.
*Parameter No.lllI, 1m, ~
cannot be cleared.
~ Display:Frequency setting bias calibration (Pr.21 will be rewrittensimultaneously. )
~ 0 isplay:Frequency setting ga in ca Ii bration (Pr.22 will be rewritten slmultenecuslv,)
If the difference of the
input voltages for the bias and gain calibration is less
than O.5V, the calibration error will occur (Er3 will display).
Setting
Details
value
0 Not executed.
1
Parameters are all cleared (initiefieed).
*
2
Frequency setting signal calibration mode is selected.
