Mitsubishi FREQROL-U100 User Manual

• Single phase 200V input series
IStandard series FR U120S 0 (UL)
O.lK
O.2K OAK
O.75K
Model Low-acoustic no~s~ie~ (I 1 )
O.1K
O.2K OAK
0.75K
FR-U120S-N - UL
Applicable motor capacity (kW)/(HP) * 1
0.1/1/8
0.2/1/4 0.4/1/2 0.75/1
Rated capacity (kVA)
*2
0.3
0.5 0.9 1.5
Rated output current (A) 0.8
1.4 2.4 4.1
Output
Overload current rating
*3
150% 60 sec. 200% u.s sec. (inverse time characteristic)
Rated output voltage *4
s-pnese 200 to 220V (The model of UL type is 200 to 230V)
Rated input AC voltage
Single ohese 200V 50Hz. 200to zarv 60Hz (ULtype ~ 200 to 230V, 50/60Hz)
Power
Tolerable AC voltage fluctuation
180to 220V SOHz, 180to 242V 60Hz (UL type is 180to 253V,50/60Hz)
supply
Tolerable frequency fluctuation 5%
Power supply capacity (kVA) *5
0.5
I
0.9
I
1.5
I
2.5
Enclosure
Enclosed type (I P20)
Cooling method
Self-cooling (without cooling fan)
Weight (kg)
0.6
I
0.7
I
0.9
I
1.7
(Note)
*1. The maximum applicable capacity is for the Mitsubishi standard motor 4p, This may not apply to the 6P motor.
so refer to the rated
output current.
*2. The rated capacity is shown for the
output voltage of 220V (60Hz).
*3. The overload current value
% shows the ratio to the inverter's rated output current.
*4. The
output voltage cannot exceed the power supply voltage.
*5. The necessary power capacity willdiffer according to the impedanceon the power supply side(including reactor and
power wires on input side). Prepare a power supply capacity higher than the noted value.
*6. If a load isapplied on the motor. the
output voltage willdrop approx. \0 to 15%. so the load must be reduced
when using a general purpose motor.
*7. The lcw-ecoustio noise. fully enclosedtype wl11 be O.lkgheavier.
-49-
