1.5K
Installation
screw
M4
(4 places)
(Unit:
nm)
Prot~tiV,
~v,r
~.5
(Note)
For 0.75 and
15K
drive. heatsink is
standard,
so the temprereture will rise
by
approx. 30
degrees depending on the usage conditions.
(Note) The
UK
drive comes equipped
with
a fan.
-70-
