Mitsubishi LE-40MTA-E - Operation Procedures; Setting and Changing Settings

6
3.1 Setting and change of settings
When two or more items are displayed on the screen, one of them can be selected using the following pro-
cedure. The selected item is marked with "  ", and held in the memory even while the power is interrupted.
When the menu items cannot be displayed on one screen, they can be scrolled and displayed using the
cursor control keys ( ).
1. Selection of item on screen
T S
Flashing cursor is
placed at the top item .
Flashing cursor is
placed at the top item.
ENTER
Select screen
 mark flashes
Cursor
is moved
T S T S
 mark flashes
 mark is lit.
Selection is
registered.
2. odification of set value on screen
When numeric will
be set for one item
onthe screen .
When numeric will be
set for two or more
items on the screen.
Select the desierd item using the cursor
control keys and ENTER key.
This selection procedure is not required for an
already selected item .
Perform the tension setting
(TENSION SET) and manual
setting (MANUAL SET) using the
trimmer provided on the panel
(Entering of a numeric directly is
not possible .).
The set value is modified even if
the value is not displayed on the
screen.
Increase or decrease the
displayed value using the
numeric
input keys , then press the
ENTER key for determination.
Tension setting and manual
setting are set by the trimmer, but
cannot set by the numeric input
key.
Set through panel
When indicated as "External" on
the screen, the setting changes
according to the external
controller setting to display on the
screen. (Setting can be made
without screen display .)
When the "External" indication
goes out, it indicates that the
external controller set value has
become smaller than the panel
set value.
Set by external trimmer
Normal setting
External analog input
Setting of items in use
• When an item which can
be modified is selected,
under-cursor " _ " is
displayed in the numeric
input field.
• When an item which can
not be modified is selected,
the under -cursor " _ " is
not displayed.
The fixation of a
numeric input should
push the " ENTER "
key.
3. Operation
