Mitsubishi LE-40MTA-E User Manual

50
11.4 Selection item and analog data
-------- The items cannot set during operation.
*1 : Refer to the note in the previous page.
*2 : Setting of MC5, MC6
When the control reel is set to one reel or the feed reel, never set the [cut torque] to MC5 or MC6.
Set the [cut torque] exclusively when multiple reels are selected.
*3 : Setting of AI2, AI3
When the control reel is set to the feed reel, never set the[taper ratio]or the[diameter] to AI2 or AI3.
Set the[taper ratio] or the[diameter] exclusively when the control reel is set to[winding] or[unwinding]
When the taper signals set to [external], make sure to set the winding diameter to AI2 or AI3.
When the control reel is set to one reel or the feed reel, never set the [new reel preset] to AI2 or AI3.
Set the [new reel preset] exclusively when multiple reel are selected.
• These inputs are always valid even if set screen is not displayed.
• These analog values are digitized by 12-bit A/D converter.
The monitor data contains the following items, and is not saved if power is interrupted.
• Tension monitor, total( N,x10N) • Tension, target (N,x10N)
• Tension monitor, left (N,x10N) Value based on the set tension while taking the
• Tension monitor, right (N,x10N) decrease ratio of the taper tension into account.
• Control output(0~100%) • Reel diameter input(min. diameter ~ max. diameter)
Set item Description
Initial
set
Memory
cassett
transfer
*1
Setting
during
operation
Mainly
refer
page
Selection item
Control while stop timer feed back / Fixed feed back c × 28
Unit of tension ×10N / N N c × 10
Control reel Unwinding / Winding / Feed Unwinding c × 11
Number of reels One reel / Multi reels One reel c × 11
Taper control OFF / ON OFF c × 31
Taper signal Internal / External Internal c × 31
Taper mode Linear / Nonlinear Linear c × 32
Actuator Powder / Servo Powder c × 11
Stall mode Key set / MANUAL vol. MANUAL c × 16
Stall reset MC4 / MC4+OUT SW. MC4+OUT SW. c × 15
AI2/AI3 setting
Diameter / Stall / New reel preset
/ Taper ratio / Ext. tension
Not set c ×
48
*2
MC5/MC6 setting
Gain 2 / Inching / OUT remote
/ Cut torque
Not set c ×
48
*3
Number of detectors 2 / 1 2 c × 12
Automatic gain Automatic / Manual Manual c × 34
Name Unit Digital data for analog value of 0~5V Increment Remark
Internal
Manual torque % 0 ~ 100 1
Tension setting
N
0 ~ full scale tension
1
×10N 0.1
External
Tension
setting(AI1)
N
0 ~ full scale tension
1
×10N 0.1
Tension detec-
tor (auxiliary)
N
0 ~ full scale tension
1
Terminals AI2 and AI3
are set by parameters.
×10N 0.1
Taper ratio
setting
%
0 ~ 8 0 % ( 0 = S e t t e n s i o n ) : I n t . d i a m e t e r
1
0 ~100%(0=Set tension):Ext.diameter
Stall setting % 0 ~100% 1
New reel preset % 0 ~100% 1
Diameter input mmφ min. diameter ~ max. diameterÅÖ2000 11
1. Selection item
2. Analog data
3. Monitor data
