4.10.3 Keyboard for 8.4-type Display Unit (FCU8-KB029)
[Outline dimension]
(Note) The above side view shows the state with the operation panel I/O unit mounted.
[Panel cut dimension]
[mm]
260
140
9.5
110
(Space required for wiring)
[mm]
248±0.3
260
247
246±0.3
0.5
127
113±0.3
126±0.3
(7) (7)
(7)
(7)
9
13
9
13
(6.5)
3.53.5
0.5
(6.5)
6.5±0.2
1±0.2
4-M3
140
(Unit outline)
(Unit outline)
(Square hole dimension)
(Square hole dimension)
screw
4 - 4 holes
