M800S/M80/E80 Series Connection and Setup Manual
24 Setting the Machine Error Compensation
500
IB-1501269-J
24.1.3.2 Using a Rotary Axis as Basic Axis
The sum of the compensation amounts set with the incremental amount method is always "0".
In the absolute amount method, the compensation amount at the terminal point (360 degrees) is always "0".
Division point number #4123 #4124 #4125 #4126 #4127 #4128 rdvno 4122
Compensation
amount
Incremental
amount method
-42062-6mdvno4123
Absolute
amount method
-4 -2 -2 4 6 0 pdvno 4128
#4124#4123 #4126 #4127
2
1
-1
-2
-3
(-2) (1) (0) (3) (1)
(-2)
(-1)
(2)
3
#4125
(-1)
(3)
(-3)
#4128
(0)
Compensation
amount
in incremental
amount method
360 deg
Basic axis machine
coordinate
Error
Compensation
amount
in absolute
amount method
