Mitsubishi M800S series

M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
79
IB-1501269-J
4.10.6 Keyboard for 10.4-type Display Unit (FCU8-KB047)
[Outline dimension]
(Note) The above side view shows the state with the operation panel I/O unit mounted.
[Panel cut dimension]
290
160
9.5
[mm]
110
(Space required for wiring)
[mm]
278±0.3
290
277
276±0.3
0.5
147
133±0.3 146±0.3
(7)
(7)
(7)
(7)
9
13
9
13
(6.5)
3.53.5
0.5
(6.5)
6.5±0.2
1±0.2
4-M3
160
(Unit outline)
(Unit outline)
(Square hole dimension)
(Square hole dimension)
screw
4 - 4 holes
