M800S/M80/E80 Series Connection and Setup Manual
3 List of Configuration
17
IB-1501269-J
3.4 Display Unit [M800S]
3.5 Display Unit [M80]
3.6 Display Unit [E80]
Classification Type Components Remarks
10.4-type color TFT touch panel
(VGA:640*480)
FCU8-DU141-31
LCD panel
Menu keys
Escutcheon
Base metal plate
Cable
Screw cap set
Front side memory I/F is normally equipped with
the control unit
15-type color TFT touch panel
(XGA:1024*768)
FCU8-DU181-31
LCD panel
Menu keys
Escutcheon
Base metal plate
Cable
Screw cap set
Front side memory I/F is normally equipped with
the control unit
Classification Type Components Remarks
8.4-type color TFT
(VGA:640*480)
FCU8-DU121-12
LCD panel
Menu keys
Escutcheon
Base metal plate
Cable
Screw cap set
Front side memory I/F is normally equipped with
the control unit
10.4-type color TFT touch panel
(VGA:640*480)
FCU8-DU141-32
LCD panel
Menu keys
Escutcheon
Base metal plate
Cable
Screw cap set
Front side memory I/F is normally equipped with
the control unit
15-type color TFT touch panel
(XGA:1024*768)
FCU8-DU181-32
LCD panel
Menu keys
Escutcheon
Base metal plate
Cable
Screw cap set
Front side memory I/F is normally equipped with
the control unit
Classification Type Components Remarks
8.4-type color TFT
(VGA:640*480)
FCU8-DU121-13
LCD panel
Menu keys
Escutcheon
Base metal plate
Cable
Screw cap set
Front side memory I/F is normally equipped with
the control unit
