M800S/M80/E80 Series Connection and Setup Manual

4 General Specifications

IB-1501269-J

[Installation dimension: FCU8-DX731 / FCU8-DX750 / FCU8-DX760 / FCU8-DX761 / FCU8-DX834]

(Note) The unit thickness of the fixed part with screws is 16.6mm.

Select the fixing screws having the length suitable for the thickness.

171±0.3

(5)

(4)

106±0.3

(4)

(5)

[mm]

4-M3 screw

116 (Unit outline)

179 (Unit outline)
