M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
97
IB-1501269-J
(7) CJ37 (Machine signal input)
Digital input 48 points (1st and 2nd stations)
(9) CJ39 (Machine signal input)
Digital input 48 points (2nd and 3rd stations)
The input/output assignment is modifiable using a parameter. Refer to "17.6.4.2 Arbitrary Device Assignment"
for details.
<Cable side connector type>
Connector : XG4M-5030 / 7950-6500SC
Strain relief : XG4T-5004 / 3448-7950
Recommended manufacturer : OMRON / 3M
CJ37 CJ39
BA BA
25 I X200 25 I X218 25 I X230 25 I X248
24 I X201 24 I X219 24 I X231 24 I X249
23 I X202 23 I X21A 23 I X232 23 I X24A
22 I X203 22 I X21B 22 I X233 22 I X24B
21 I X204 21 I X21C 21 I X234 21 I X24C
20 I X205 20 I X21D 20 I X235 20 I X24D
19 I X206 19 I X21E 19 I X236 19 I X24E
18 I X207 18 I X21F 18 I X237 18 I X24F
17 I X208 17 I X220 17 I X238 17 I X250
16 I X209 16 I X221 16 I X239 16 I X251
15 I X20A 15 I X222 15 I X23A 15 I X252
14 I X20B 14 I X223 14 I X23B 14 I X253
13 I X20C 13 I X224 13 I
X23C 13 I X254
12 I X20D 12 I X225 12 I X23D 12 I X255
11 I X20E 11 I X226 11 I X23E 11 I X256
10 I X20F 10 I X227 10 I X23F 10 I X257
9 I X210 9 I X228 9 I X240 9 I X258
8 I X211 8 I X229 8 I X241 8 I X259
7 I X212 7 I X22A 7 I X242 7 I X25A
6 I X213 6 I X22B 6 I X243 6 I X25B
5 I X214 5 I X22C 5 I X244 5 I X25C
4 I X215 4 I X22D 4 I X245 4 I X25D
3 I X216 3 I X22E 3 I X246 3 I X25E
2 I X217 2 I X22F 2 I X247 2 I X25F
1 DICOM 1 DICOM 1 DICOM 1 DICOM
To Next Page
