M800S/M80/E80 Series Connection and Setup Manual

4 General Specifications

113

IB-1501269-J

[Outline dimension : FCU8-DX231]

[Outline dimension : FCU8-DX202]

(Space required above the unit)(Space required below the unit)

(Space

required for

wiring)

168 2.5

45 115

[mm]

30 30

168 2.5

80 115

[mm]

(Space required for

wiring)
