Mitsubishi M800S series

M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
118
IB-1501269-J
[Installation dimension : FCU8-DX220 / FCU8-DX230 / FCU8-DX231 / FCU8-DX202 /
FCU8-DX213 / FCU8-DX213-1 / FCU8-DX654 / FCU8-DX654-1 / FCU8-DX408 / FCU8-DX409]
[Installation dimension : FCU8-DX651]
[mm]
156 ± 0.2
6
6
(Unit outline)
40
168
2-M5 Screw
4
(Unit outline)(Unit outline)
[mm]
156 ± 0.2
4
168
88 ± 0.2
100
6
6
4
3-M5 Screw
(Unit outline)(Unit outline)
(Unit outline)
