Mitsubishi M800S series User Manual

M800S/M80/E80 Series Connection and Setup Manual
10 Connection of Remote I/O Unit
303
IB-1501269-J
[Safety machine input (wiring example 2) : FCU8-DX654 / FCU8-DX654-1]
FCU8-DX654/654-1
SX00A
SX00B
SX01A
SX01B
SX02A
SX02B
SX03A
SX03B
SX04A
SX04B
SX05A
SX05B
SX06A
SX06B
SX07A
SX07B
SDI
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
0V
FG
1
2
3
DCIN
+24V
0V
FG
9
19
10
20
0V
FG
IO0VA
IO0VB
0V
FG
SDO
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
IO24VA
IO24VB
24VDC(+)
Stabilized
power supply
Machine side
24VDC(+)
Stabilized
power supply
24VDC(+)
Stabilized
power supply
