Mitsubishi M800S series

Apr.2016 IB(NA)1501269-C (Continued from the previous page)
- Chapter composition change
Title of chapter 6 was changed into "Precautions for Connecting"
Former 6.3 to 6.9 were changed into independent chapters (Chapter 7 to 12)
Explanations for connection of drive unit in former 9.3 to 9.5 were moved to a new
chapter 7
Former chapter numbers 7 to 19 were changed into 13 to 24 due to the change of
chapter 6
- Chapter number change
Section 4.10.2 was changed into 4.11.3
Chapter 17 was changed into Chapter 25
Appendix 1 to 3 were changed into Chapter 27 to 29
- Mistakes were corrected.
Oct.2016 IB(NA)1501269-D The contents were corrected to correspond with the system software C1 version.
- The following units were added.
FCU8-DX760 (Operation Panel I/O Unit)
FCU8-DX761 (Operation Panel I/O Unit)
- The following chapters and sections were added.
9.2 Connecting with Frame Ground
9.7.4 Example of Wiring CJ42 (FCU8-DX760)
9.8 Connecting with Analog I/O Signal (FCU8-DX761)
13.2.13 J224 Cable
13.3.12 MR-BKS1CBL-A1-H/MR-BKS1CBL-A2-H Cable
13.3.15 MR-PWS1CBL-A1-H/MR-PWS1CBL-A2-H Cable
24 Adjust S-analog Screen
25 Device Open Parameter Screen
26 SRAM Open Parameter Screen
- Chapter number change
Due to addition of the chapters as above, the existing chapters were renumbered.
- Chapter title change
4.8.2 FCU8-DX750/FCU8-DX760/FCU8-DX761
- Correspond with MDS-EMH.
- Mistakes were corrected.
Date of
revision
Manual No. Revision details
