Mitsubishi M800S series

Sep. 2019 IB(NA)1501269-J The descriptions of M800 Series/M80 Series/E80 Series were revised in response to
S/W version E1.
- The following units were added.
FCU8-DX834 (Operation panel I/O unit)
FCU8-EX568 (FL-net expansion unit)
- The following cable was added.
J012 (Operation panel I/O interface cable)
- The following chapters were added.
2.3.1 Connecting a Spindle Drive Unit
2.3.2 Connecting a Pulse-controlled Inverter
3.26 System Type
4.14.5 FL-net (FCU8-EX568)
7.7 Connecting with Pulse-controlled Inverter [E80]
7.12.5 Connecting I/O Device via FL-net
9.2 Connecting with Power Supply
9.8.5 Connection with the scan input signal (FCU8-DX834)
9.8.6 Connection with the scan output signal (FCU8-DX834)
15.2.7 J012 cable
20.8 Setting the Communication with GX Works2
20.9 Setting the Parameters on GX Works2
20.10 Writing a Sequence Program with GX Works2
20.11 Writing a Sequence Program to ROM with GX Works2
24 Setting the Machine Error Compensation
25 Setting the Position Switches
26 Setting the Backlash Compensation
- The following contents were changed.
2.1 General Connection Diagram [M800S]
2.2 General Connection Diagram [M80]
2.3 General Connection Diagram [E80]
3.1 Control Unit [M800S]
3.10 Operation Panel I/O Unit
3.14 Communication Expansion Unit
3.25 List of Cables
4.1.1 Installation Environment Conditions
4.2.1 Installation Environment Conditions
4.3.1 Installation Environment Conditions
4.4.1 FCU8-MU542 / FCU8-MA542 / FCU8-MU541 / FCU8-MA541
4.6.1 FCU8-MU513 / FCU8-MU514
4.7.1 10.4-type (FCU8-DU141-31)
4.7.2 15-type (FCU8-DU181-31)
4.8.1 8.4-type (FCU8-DU121-12)
4.8.2 10.4-type (FCU8-DU141-32)
4.8.3 15-type (FCU8-DU181-32)
4.9.1 8.4-type (FCU8-DU121-13)
4.11 Operation Panel I/O Unit
4.11.1 List of Units
4.11.2 FCU8-DX731 / FCU8-DX750/ FCU8-DX760 / FCU8-DX761 / FCU8-DX834
4.12.2 FCU8-DX220 / FCU8-DX230 / FCU8-DX231 / FCU8-DX202 / FCU8-DX213 /
FCU8-DX213-1 / FCU8-DX654 / FCU8-DX654-1 / FCU8-DX651 / FCU8-DX408 /
FCU8-DX409
(Continue to the next page)
Date of
revision
Manual No. Revision details
