128
LDPI, LDFI, ANDPI, ANDFI, ORPI, ORFI
Operation Error
(1) There is no operation error in the LDP, LDF, ANDP, ANDF, ORP, or ORF instruction.
Program Example
(1) The following program executes the MOV instruction at input X0, or at the leading edge of b10 (bit 11) of data register
D0.
[Ladder Mode] [List Mode]
*1: Word device bit designation is performed in hexadecimal. Bit b10 of D0 will be D0.A.
: Devices used as contacts (bits)
5.1.3 LDPI, LDFI Pulse NOT operation start
ANDPI, ANDFI Pulse NOT series connection
ORPI, ORFI Pulse NOT parallel c onnection
5.1.3 LDPI, LDFI, ANDPI, ANDFI, ORPI, ORFI
• QnU(D)(H)CPU, QnUDE(H)CPU: The serial number (first five
digits) is "10102" or later.
Setting
Data
Internal Devices
R, ZR
J\
U\G
Zn Constants
Other
DX
Bit Word Bit Word
––
*1
Step
Instruction
Device
Basic
High
performance
Process Redundant Universal LCPU
Ver.
X1/D0.1
X1/D0.1
X2/D0.2
X2/D0.2
X3/D0.3
X3/D0.3
LDPI
LDFI
ORPI
ANDPI
ANDFI
ORFI
Bit device number / Word device bit designation ( )
S
S
S
