SFTWR, SFTWRP, SFTWL, SFTWLP
Program Example
(1) The following program shifts the contents of D683 to D689 to the right when XB is turned ON.
[Ladder Mode] [List Mode]
[Operation]
(2) The following program shifts the contents of D683 to D689 to the left when XB is turned ON.
[Ladder Mode] [List Mode]
[Operation]
: Head number of the devices to be shifted (BIN 16 bits)
n1 : Number of words to be shifted (BIN 16 bits)
n2 : Number of shifts (BIN 16 bits)
7.3.5 SFTWR, SFTWRP n-word shift to ri ght of n-word data
SFTWL, SFTWLP n-word shift to left of n-word data
7.3.5 SFTWR, SFTWRP, SFTWL, SFTWLP
• QnU(D)(H)CPU, QnUDE(H)CPU: The serial number (first five
digits) is "10102" or later.
Setting
Data
Internal Devices
R, ZR
J\
U\G
Zn
Constants
K, H
Other
Bit Word Bit Word
–– –– ––
n1 –– ––
n2 –– ––
Step Instruction Device
D686
D686D689 D688 D687 D685 D684 D683
D689 D688 D687 D685 D684 D683
503 600 3802
5003
0 503 600 3802
Filled with 0.
Designation range for the DSFRP instruction
-32765-336-100
-100 -336
-32765
Step Instruction Device
D686
D686D689 D688 D687 D685 D684 D683
D689 D688 D687 D685 D684 D683
-100 503 600 -336 3802 -32765 5003
503 600 -336 3802 -32765 5003 0
Filled with 0.
Designation range for the DSFLP instruction
Basic
High
performance
Process Redundant Universal LCPU
Ver.
Command
Command
SFTWR, SFTWL
SFTWRP, SFTWLP
P
n2
n2
D
n1
n1
D
indicates an instruction symbol of SFTWR/SFTWL.
D
D
